EN 50155 8- to 18-port Ethernet switches with up to 8 PoE ports and up to 2 Gigabit ports


The ToughNet TN-5500A Series M12 managed Ethernet switches are designed for railway applications, such as rolling stock, and wayside installations. The TN-5500A Series switches use M12 and other circular connectors to ensure tight, robust connections, and guarantee reliable operation against environmental disturbances, such as vibration and shock. The TN-5500A Series Ethernet switches provide 8 or 16 Fast Ethernet M12 ports with or without 8 IEEE 802.3at/af compliant PoE (Power-over-Ethernet) ports, and 2 ports on the down side to provide the Gigabit Ethernet interface with an optional bypass relay function. The PoE switches are classified as power source equipment (PSE) and provide up to 30 watts of power per port, and can be used to power IEEE 802.3at/af compliant powered devices (PDs), such as IP surveillance, wireless access points, and IP phones.

The TN-5500A Series provides a wide power input range of 24/36/48/72/96/110 VDC that allows you to use the same type of power source at different sites around the globe. In addition, the 24 to 110 VDC wide power input range and isolated power increases the reliability of your communications system. In addition, the -40 to 75°C operating temperature and IP54 rated waterproof enclosure allow deployment in harsh environments. TN-5500A Series Ethernet switches are compliant with mandatory sections of EN 50155, covering operating temperature, power input voltage, surge, ESD, and vibration, as well as conformal coating and power insulation, making the switches suitable for a variety of industrial applications.
Sort By:
Page of 1
Moxa TN-5508A-8PoE-WV-T TN-5508A-8PoE-WV-T

Moxa 8 port Managed Ethernet Switch w/(8) M12 10/100BTX 802.3at PoE+ ports & 24 - 110 VDC power input (extended temperature model)

ESP Price: $2,219.44
Moxa TN-5508A-WV-CT-T TN-5508A-WV-CT-T

Moxa L2 Managed Ethernet switch w/(8) 10/100BTX M12 ports, 24 - 110 VDC, 18W dual power input, conformal coating (extended temperature model) Version 1.0.1

ESP Price: $2,137.54
Moxa TN-5508A-WV-T TN-5508A-WV-T

Moxa L2 managed switch w/(8) 10/100BTX M12 Ports, dual power input, 24 to 110 VDC, & 18W (extended temperature model) Version 1.0.1

ESP Price: $1,981.09
Moxa TN-5510-2GLSX-ODC-LV-WV-T TN-5510-2GLSX-ODC-LV-WV-T

Moxa L2 Managed Ethernet Switch w/(8) M12 10/100BTX ports, (2) GE multimode 2km ODC fiber ports & 12/24/36/48 VDC or 24-110 VDC (extended temperature model)

ESP Price: $3,761.89
Moxa TN-5510A-2GLSX-ODC-WV-CT-T TN-5510A-2GLSX-ODC-WV-CT-T

Moxa L2 Managed Ethernet switch w/(8) 10/100BTX and (2) 1000 BaseLSX Q-ODC ports, 24 - 110 VDC, 18W dual power input, conformal coating (extended temperature model) Version 1.0.1

ESP Price: $4,054.05
Moxa TN-5510A-2GLSX-ODC-WV-T TN-5510A-2GLSX-ODC-WV-T

Moxa L2 Managed Ethernet switch w/(8) 10/100BTX and (2) 1000 BaseLSX Q-ODC ports, 24 - 110 VDC, 18W dual power input (extended temperature model) Version 1.0.1

ESP Price: $3,504.90
Moxa TN-5510A-2GTX-WV-CT-T TN-5510A-2GTX-WV-CT-T

Moxa L2 Managed Ethernet switch w/(8) 10/100BTX and (2) 10/100/1000 BTX M12 ports, 24 - 110 VDC, 18W dual power input, conformal coating (extended temperature model) Version 1.0.1

ESP Price: $2,827.13
Moxa TN-5510A-2GTX-WV-T TN-5510A-2GTX-WV-T

Moxa L2 Managed Ethernet switch w/(8) 10/100BTX and (2) 10/100/1000 BTX M12 ports, 24 - 110 VDC, 18W dual power input (extended temperature model)  Version 1.0.1

ESP Price: $2,612.14
Moxa TN-5510A-2GTXBP-WV-CT-T TN-5510A-2GTXBP-WV-CT-T

Moxa L2 Managed Ethernet switch w/(8) 10/100BTX and (2) 10/100/1000 BTX M12 ports with bypass relay function, 24 - 110 VDC, 18W dual power input, conformal coating (extended temperature model) Version 1.0.1

ESP Price: $2,885.40
Moxa TN-5510A-2GTXBP-WV-T TN-5510A-2GTXBP-WV-T

Moxa L2 Managed Ethernet switch w/(8) 10/100BTX and (2) 10/100/1000 BTX M12 ports with bypass relay function, 24 - 110 VDC, 18W dual power input (extended temperature model) V1.0.1

ESP Price: $2,675.14
Moxa TN-5510A-8PoE-2GLSX-ODC-WV-CTT TN-5510A-8PoE-2GLSX-ODC-WV-CT-T

Moxa 8+2G Managed Ethernet Switch w/(8) 10/100BTX 802.3at PoE+ M12 ports & (2) Gigabit fiber ports, 24 - 110 VDC power input & conformal coating (extended temperature model)

ESP Price: $4,287.94
Moxa TN-5510A-8PoE-2GLSX-ODC-WV-T TN-5510A-8PoE-2GLSX-ODC-WV-T

Moxa 8+2G Managed Ethernet Switch w/(8) 10/100BTX 802.3at PoE+ M12 ports & (2) Gigabit fiber ports & 24 - 110 VDC power input (extended temperature model)

ESP Price: $3,972.41
Moxa TN-5510A-8PoE-2GTX-WV-CT-T TN-5510A-8PoE-2GTX-WV-CT-T

Moxa 8+2G Managed Ethernet Switch w/(8) 10/100/BTX 802.3at PoE+ ports, (2) Gigabit M12 ports, 24 - 110 VDC power input & conformal coating (extended temperature model)

ESP Price: $3,060.75
Moxa TN-5510A-8PoE-2GTX-WV-T TN-5510A-8PoE-2GTX-WV-T

Moxa 8+2G Managed Ethernet Switch w/(8) 10/100/BTX 802.3at PoE+ ports, (2) Gigabit M12 ports & 24 - 110 VDC power input (extended temperature model)

ESP Price: $2,838.68
Moxa TN-5510A-8PoE-2GTXBP-WV-CT-T TN-5510A-8PoE-2GTXBP-WV-CT-T

Moxa 8+2G Managed Ethernet Switch w/(8) 10/100/BTX 802.3at PoE+ ports, (2) Gigabit M12 ports with bypass function, 24 - 110 VDC power input & conformal coating (extended temperature model)

ESP Price: $3,189.38
Moxa TN-5510A-8PoE-2GTXBP-WV-T TN-5510A-8PoE-2GTXBP-WV-T

Moxa 8+2G Managed Ethernet Switch w/(8) 10/100/BTX 802.3at PoE+ ports, (2) Gigabit M12 ports with bypass function & 24 - 110 VDC power input (extended temperature model)

ESP Price: $2,955.49
Moxa TN-5516A-8PoE-WV-CT-T TN-5516A-8PoE-WV-CT-T

Moxa L2 Managed Ethernet switch w/(8) 10/100BTX ports, (8) 802.3at PoE+ M12 connectors & conformal coating (extended temperature model)

ESP Price: $3,154.20
Moxa TN-5516A-8PoE-WV-T TN-5516A-8PoE-WV-T

Moxa L2 Managed Ethernet switch w/(8) 10/100BTX ports, (8) 802.3at PoE+ M12 connectors & 24 - 110 VDC (extended temperature model)

ESP Price: $2,920.58
Moxa TN-5516A-WV-CT-T TN-5516A-WV-CT-T

Moxa 16 port L2 managed Ethernet switch w/(16) 10/100BTX M12 ports, dual power input, 24 to 110 VDC, 18W, conformal coating (wide temperature model) Version 1.0.2

ESP Price: $2,920.58
Moxa TN-5516A-WV-T TN-5516A-WV-T

Moxa 16 port L2 managed Ethernet switch w/(16) 10/100BTX M12 ports, dual power input, 24 to 110 VDC, 18W (extended temperature model) Version 1.0.2

ESP Price: $2,686.69
Moxa TN-5518A-2GTX-WV-CT-T TN-5518A-2GTX-WV-CT-T

Moxa 16 port L2 managed Ethernet switch w/(16) 10/100BTX ports, (2) 10/100/1000BTX ports with M12 connectors, dual power input, 24 to 110 VDC, 18W, conformal coating (extended temperature model) Version 1.0.2

ESP Price: $3,504.90
Moxa TN-5518A-2GTX-WV-T TN-5518A-2GTX-WV-T

Moxa 16 port L2 managed Ethernet switch w/(16) 10/100BTX ports, (2) 10/100/1000BTX ports with M12 connectors, dual power input, 24 to 110 VDC, 18W (extended temperature model) Version 1.0.2

ESP Price: $3,154.20
Moxa TN-5518A-2GTXBP-WV-CT-T TN-5518A-2GTXBP-WV-CT-T

Moxa 16 port L2 managed Ethernet switch w/(16) 10/100BTX ports, (2) 10/100/1000BTX ports with M12 connectors, (2) Gigabit ports with bypass relay function, dual power input, 24 to 110 VDC, 18W conformal coating (extended temperature model) Version 1.0.2

ESP Price: $3,504.90
Moxa TN-5518A-2GTXBP-WV-T TN-5518A-2GTXBP-WV-T

Moxa 16 port L2 managed Ethernet switch w/(16) 10/100BTX ports, (2) 10/100/1000BTX ports with M12 connectors, (2) Gigabit ports with bypass relay function, dual power input, 24 to 110 VDC, 18W (extended temperature model) Version 1.0.2

ESP Price: $3,271.01
Moxa TN-5518A-8PoE-2GTX-WV-CT-T TN-5518A-8PoE-2GTX-WV-CT-T

Moxa L2 Managed Ethernet switch w/(8) 10/100BTX ports, (8) 802.3at PoE+ M12 connectors, (2) 10/100/1000 BTX M12 connectors & conformal coating (extended temperature model)

ESP Price: $4,100.78
Moxa TN-5518A-8PoE-2GTX-WV-T TN-5518A-8PoE-2GTX-WV-T

Moxa L2 Managed Ethernet switch w/(8) 10/100BTX ports, (8) 802.3at PoE+ M12 connectors, (2) 10/100/1000 BTX M12 connectors (extended temperature model)

ESP Price: $3,797.06
Moxa TN-5518A-8PoE-2GTXBP-WV-CT-T TN-5518A-8PoE-2GTXBP-WV-CT-T

Moxa L2 Managed Ethernet switch w/(8) 10/100BTX ports, (8) 802.3at PoE+ M12 connectors, (2) 10/100/1000 BTX M12 connectors with bypass function & conformal coating (extended temperature model)

ESP Price: $4,236.75
Moxa TN-5518A-8PoE-2GTXBP-WV-T TN-5518A-8PoE-2GTXBP-WV-T

Moxa L2 Managed Ethernet switch w/(8) 10/100BTX ports, (8) 802.3at PoE+ M12 connectors, (2) 10/100/1000 BTX M12 connectors with bypass function (extended temperature model)

ESP Price: $3,921.23
