Home > Digi > Digi Cellular Routers > Digi Transportation Cellular Routers > Digi WR11 XT >

WR11-C200-DE1-SU

See any errors on this page?
Please let us know.

Alternative Views:

Digi TransPort WR11 - Verizon (3G), includes antenna and US power supply

ESP Price: $299.00

Contact us for Partner Pricing. (more info)

Availability: Usually Ships in 24 Hours; However, Due To Shortages Contact Sales to Verify
Product Code: WR11-C200-DE1-SU

Description

Technical Specs

Drivers & Downloads

Digi TransPort® WR11

Secure 3G/4G LTE cellular router for retail, kiosk and industrial control applications

Digi TransPort WR11 delivers a cost-optimized 4G LTE connection to mission critical M2M applications around the world. The router comes with Digi’s enterprise software configuration by default, which means network administrators have the routing, security, VPN and stateful firewall tools they need to create a PCI compliant network right out of the box. Digi management solutions provide easy setup, configuration and maintenance of large installations of remote Digi TransPort devices. Digi Remote Manager® offers web-based device management for remote Digi cellular routers and gateways.

WR11 Accessories:

76000926 - Antenna - Cellular, LTE 746-2700MHz
76000934 - AC Power Supply
76000976 - WR11/WR11XT 9-30VDC Power Adapter (will allow WR11 routers to operate in 9-30VDC environment)

Documentation

WR11 Data Sheet

WR11 XT Data Sheet

Quick Start Guide (EVDO Models)

Quick Start Guide (HSPA+ Models)

Quick Start Guide (LTE Models)

Quick Start Guide (XT Models)

User Manual

Digi Transport Comparison

Digi Remote Manager Data Sheet

Digi Remote Manager User Manual

SPECIFICATIONS	Digi TransPort WR11
3G/4G LTE SPECS
LTE – NORTH AMERICA (L6)	LTE CAT 3: 700(B17)/850(B5)/AWS(B4)/1900(B2) 3G HSPA+: 850/1900 MHz 2G Edge: 850/1900 MHz Transfer rate (max): 100 Mbps down, 50Mbps up Approvals: PTCRB, AT&T, Telus, Bell
LTE – VERIZON (L8)	Coverage: United States LTE CAT 3: 700(B13)/AWS(B4) Transfer rate (max): 100 Mbps down, 50Mbps up Approvals: Verizon
LTE – EMEA/APAC (L7)	LTE CAT 3: 800(B20)/1800(B3)/2600(B7) 3G HSPA+: 900/2100 MHz 2G Edge/GPRS: 850/900/1800/1900 MHz Transfer rate (max): 100 Mbps down, 50Mbps up Approvals: Vodafone
GLOBAL HSPA+ - (U9)	3G HSPA+: 850/900/1700AWS/1900/2100 MHz 2G EDGE/GPRS: 850/900/1800/1900 MHz Transfer rate (max): 21 Mbps down, 5.76 Mbps up Approvals: PTCRB, Vodafone
CONNECTORS	(2) 50 Ω SMA (Center pin: female); (1) connector for non-LTE models
SIM SLOTS	(2) Mini-SIM (2FF)
SIM SECURITY	Snap-fit SIM cover
SOFTWARE & MANAGEMENT
REMOTE MANAGEMENT	Digi Remote Manager® (cloud based); SNMP v1/v2c/v3 (user installed/managed)
LOCAL MANAGEMENT	WebUI (HTTP/HTTPS); CLI (Telnet, SSH, SMS)
MANAGEMENT/ TROUBLESHOOTING TOOLS	FTP, SFTP, SCP; Protocol analyzer with PCAP for Wireshark; Event logging with Syslog and SMTP; NTP/SNTP
MEMORY	20 MB RAM, 10 MB file space
ETHERNET
PORTS	(1) RJ-45; 10/100 Mbps (auto-sensing)
PHYSICAL
DIMENSIONS (L X W X H)	3 in x 4 in x 1 in (7.62 cm x 10.16 cm x 2.54 cm)
WEIGHT	0.25 lb (0.11 kg)
STATUS LEDS	Power on, WWAN signal strength, WWAN service
ENCLOSURE	Polycarbonate / IP30
POWER REQUIREMENTS
POWER INPUT	5Vdc, 15W minimum power source required
POWER SUPPLY	Must be used with a Digi approved power supply
POWER CONSUMPTION	3.5W typical (Idle); 10W typical (Peak Tx/Rx)
ENVIRONMENTAL
OPERATING TEMPERATURE	0° C to +40° C (32° F to +104° F)
RELATIVE HUMIDITY	5% to 95% (non-condensing)
APPROVALS
CELLULAR	PTCRB
SAFETY	UL 60950, CSA 22.2 No. 60950, EN60950
EMISSIONS/IMMUNITY	CE, FCC Part 15 Class B, AS/NZS CISPR 22, EN55024, EN55022 Class B
WARRANTY
PRODUCT WARRANTY	5 years

Features

Global HSPA+ and 4G LTE support and certification
Extremely resilient cellular connection through patented Digi SureLink™, VRRP+ protocol and dual SIM slots
Enterprise routing features for security, logging and redundancy (e.g., stateful firewall, VPN, SNMP); no annual enterprise software license required
Digi Remote Manager provides mass configuration, device management and troubleshooting tools
5-year warranty standard—no additional cost

Digi Remote Manager

ACCESS DATA AND MANAGE DEVICES FROM ANYWHERE:
