TCC-120

Moxa TCC-120
See any errors on this page?
Please let us know.

Alternative Views:
Moxa RS422/485 DIN-Rail mountable converter/repeater, terminal block to terminal block w/surge protection
ESP Price: $184.12
Contact us for Partner Pricing. (more info)


Free Shipping
Availability: Usually Ships in 24 Hours; However, Due To Shortages Contact Sales to Verify
Product Code: TCC-120

Description Technical Specs Drivers & Downloads

The TCC-120 and TCC-120I are RS-422/485 converters/repeaters designed to extend RS-422/485 transmission distance. Both products have a superior industrial-grade design that includes DIN-rail mounting, terminal block wiring, and external terminal block for power. In addition, the TCC-120I supports optical isolation for system protection. The TCC-120 and TCC-120I are ideal RS-422/485 converters/repeaters for critical industrial environments.

Features
  • Boost serial signal to extend transmission distance
  • Wall or DIN-rail mounting
  • Terminal block for easy wiring
  • Power input from terminal block
  • DIP switch setting for built-in terminator (120 ohms)
  • Boost RS-422 or RS-485 signal, or convert RS-422 to RS-485
  • 2 KV isolation protection (TCC-120I)
