Moxa MPC-3100-E4-LB-T - Express Systems & Peripherals

Home > Moxa > Moxa Industrial Computing > Panel Computers & Displays > MPC-3100 Series >

MPC-3100-E4-LB-T

See any errors on this page?
Please let us know.

Alternative Views:

Moxa 10.4 inch Touch Panel Computer [Intel Atom Elkhart Lake qual-core x6425E CPU] w/ 8GB DDR4, 400-nits LCD (multi-touch), (2) USB3.0, (2) RS232/422/485, (2) GigaLan & 12/24VDC (ext temp)

ESP Price: $2,543.89

Contact us for Partner Pricing. (more info)

Availability: Usually Ships in 24 Hours; However, Due To Shortages Contact Sales to Verify
Product Code: MPC-3100-E4-LB-T

Description

Technical Specs

Drivers & Downloads

Introduction

The MPC-3100 10.4-inch panel computers with Intel Atom® x6211E dual-core or x6425E quad-core processor deliver a reliable, durable, and versatile platform for use in industrial environments. With two software selectable RS-232/422/485 serial ports and two Gigabit Ethernet ports, the MPC-3100 panel computers support a wide variety of serial interfaces as well as high-speed IT communications, all with native network redundancy.

The MPC-3100 panel computers are designed for the -30 to 60°C temperature range, and come with a fanless, streamlined enclosure designed for highly efficient heat dissipation. This makes the computers reliable industrial platforms for harsh, hot, outdoor environments like oil and gas fields and drilling platforms. The MPC-3100 also features a 400–nit or 1000–nit LCD panel offering a sunlight-readable, projected-capacitive, glove-friendly, multi-touch screen for an excellent user experience in outdoor applications.
