Advantech EKI-2725I-CU
See any errors on this page?
Please let us know.

Alternative Views:
Advantech 5-port Ind. Unmanaged GbE Switch W/T
ESP Price: $228.00
Contact us for Partner Pricing. (more info)


Free Shipping
Availability: Usually Ships in 24 Hours; However, Due To Shortages Contact Sales to Verify
Product Code: EKI-2725I-CU

Description Technical Specs Drivers & Downloads

The EKI-2725 supports Gigabit Ethernet, has a +12 ~ 48 VDC redundant input design, and is secured with a double protection mechanism: power polarity reverse protect and an
overload current fuse. The former tolerates reverse power wiring while the latter secures the system from overload currents. Each port of the EKI-2725 has 2 LEDs to show the link
status transmission speed and collision status and a relay output for alarm events. In the case of power failure, the built-in LED will activate the alarm to notify administrators. Engineers
can simply verify the hardware status by checking the LED and perform troubleshooting easily and quickly. The EKI-2725 comes in a compact metal housing with an IP30 rating to
protect against dusty industrial environments.
Features
  • Provides 5 Gigabit Ethernet ports with Auto MDI/MDI-X
  • Supports 10/100/1000 Mbps Auto Negotiation
  • Supports jumbo frame transmission up to 9kbytes
  • Provides Slim size, DIN-rail with IP30 metal mechanism
  • Supports Redundant 12 ~ 48 VDC power input and P-Fail Relay
