CTK-Z1201

Digi CTK-Z1201
See any errors on this page?
Please let us know.

Alternative Views:
Digi I/O Controller Multifunction 16-Port, RS485, w/ DIN Mount Enclosure
ESP Price: $225.00
Contact us for Partner Pricing. (more info)


Free Shipping
Availability: Usually Ships in 24 Hours; However, Due To Shortages Contact Sales to Verify
Product Code: CTK-Z1201

Description Technical Specs Drivers & Downloads

Digi Z1201 is a 16-pin, multifunction I/O module consisting of 8 open collector outputs, and 8 multifunction inputs, each of which can be configured under software control for analog, digital or pulse operation.
Features
  • Versatile industrial-rated I/O module
  • 8 open controller output options
  • 8 multi-mode inputs configurable to analog, digital or pulse
  • RS-485 communications
  • Natively supports 0-5 V analog, digital and pulse inputs
  • Extends to 0-10 V, 4-20 mA and 24 V sensors with external hardware
  • Switch selectable pull-ups
  • Switch selectable RS-485 termination
  • Daisy-chain power and communications to support multiple I/O modules and other RS-485 devices
  • Conformal coated and DIN rail mountable
